Ultraheat Compact 6 HS Double Panel Single Conv Vertical Radiators

Easy-fit, high efficiency radiators with a wide choice of sizes and shapes to suit any room at home or in the workspace.

Ultraheat Compact 6 vertical radiators feature two pairs of underside vertical tappings, providing a choice of widely-spaced paired valves, or a central, under-mounted H valve or most conventional paired valves.

The flow direction must be left to right and the air-vent should be positioned on the right.

The Compact 6 vertical radiators have new anti-lift brackets that clasp the convectors/back panels and have no top grills.

All tappings are ½” BSP female and are compatible with both parallel-threaded + O-ring or taper-threaded valve tails.

White RAL 9016
10 year guarantee
Delivered usually within 2/3 working days

Please note for every purchase that includes this item, it will incur a single £15 excl vat carriage charge. This will be added automatically at checkout.

Model	Height (mm)	Width (mm)	Watts 50 degrees	Btu's 50 degrees	Depth (mm)	Wall to Face (mm)	Wall to Pipe Centres (mm)
18VHS400	1800	400	1332	4545	77	104	65
18VHS500	1800	500	1665	5681	77	104	65
18VHS600	1800	600	1998	6817	77	104	65
20VHS400	2000	400	1440	4913	77	104	65
20VHS500	2000	500	1800	6142	77	104	65
20VHS600	2000	600	2160	7370	77	104	65
