TRC Ancona Made to Order 3 Column 600mm High Radiators in RAL Colours

SKU
ANCO3C60/RAL
TRC Ancona Made to Order 3 Column 600mm High Radiators in RAL Colours

The Radiator Company Ancona Made to Order steel multi column radiator allows you maximum flexibility to create a radiator that matches your exact requirements. A vast array of over 500,000 sizes can be achieved by combining column depth, height and number of sections to achieve your desired output without compromising space. There is further flexibility due to the choice of mounting options available. The Ancona boasts the highest heat output of any multi column radiator sold in the UK. For radiators that are longer than 40 sections, a joinig key will be required on site.

Available in a wide choice of 188 RAL Colours as well as 36 Classic Colours including metallics, mottled, textured effects as well as bare metal lacquer. Galvanised finish is also available on a separate listing.

All wall bracket options are included for free but please select your requirement from the drop down box above when placing your order.
The Ancona radiator can be mounted in five different ways; for a contemporary look choose Welded Feet; for a classic look choose Cast Feet; or by selecting Wall Brackets you can position your steel multi column at any height - please select your required mounting option above. Wall Ties are included in the price and supplied as standard for all orders.

As the Ancona Made to Order range is bespoke, please allow 4 weeks for delivery of RAL Colours / Classic Colours and 6 weeks for Bare Metal Lacquer. This range is considered a Special Order product line as it is made specifically to your requirements and as such is non-returnable. The Radiator Company Ancona is also available from stock in white finish for the more popular sizes with delivery usually being within 3-5 working days - Please see our separate listings.

There are so many size options within the Ancona Made to Order range that we can't possibly list them all! so please get in touch if you can't see the size that you require.

10 YEAR GUARANTEE

PLEASE NOTE: Lengths quoted have been calculated at 45mm per section plus an allowance of 24mm for bushes.

Model No of Sects Width (mm) Watts 50 degrees Btu's 50 degrees
ANCO3C60R/8 8 384 480 1640
ANCO3C60R/12 12 564 720 2460
ANCO3C60R/13 13 609 793 2665
ANCO3C60R/14 14 654 840 2870
ANCO3C60R/15 14 699 930 3075
ANCO3C60R/16 16 744 960 3280
ANCO3C60R/17 17 789 1088 3485
ANCO3C60R/18 18 834 1080 3690
ANCO3C60R/19 19 879 1216 3895
ANCO3C60R/20 20 924 1200 4100
ANCO3C60R/22 22 1014 1320 4510
ANCO3C60R/24 24 1104 1440 4920
ANCO3C60R/26 26 1194 1560 5330
ANCO3C60R/28 28 1284 1680 5740
ANCO3C60R/30 30 1374 1800 6150
ANCO3C60R/32 32 1464 1920 6560
Full Features
Brand The Radiator Company
SKU ANCO3C60/RAL
Columns 3 Column
