MHS Liberty 660mm High Cast Iron Column Radiators in Primer Finish

SKU
LIB660-B PRIMER
MHS Liberty 660mm High Cast Iron Column Radiators in Primer Finish

MHS Liberty 660mm High Cast Iron Column Radiators in Primer Finish

The MHS Liberty is made from cast iron and supplied in Umber Grey Primer as standard that requires over painting, with painted finishes available at additional cost. The radiator has a maximum working pressure of 6 bar with a maximum test pressure of 7.8 bar (water test only). Feet and wall ties are supplied as standard. All radiators are supplied with ½” bsp-f (BBOE) connections, ¾”or 1” connections.

The MHS Liberty radiator carries a 10-year guarantee against manufacturing defects.

Please allow 1 weeks for delivery of Primer Finish MHS Liberty radiators.

Model Height (mm) No of Sections Width (mm) Depth D1 Depth D2 Wall to Face Pipe Centres From Wall Watts
LIB660-B-6 660 6 480 203mm 235 or 245mm 134 or 144mm 624
LIB660-B-7 660 7 556 203mm 235 or 245mm 134 or 144mm 728
LIB660-B-8 660 8 632 203mm 235 or 245mm 134 or 144mm 832
LIB660-B-9 660 9 708 203mm 235 or 245mm 134 or 144mm 936
LIB660-B-10 660 10 784 203mm 235 or 245mm 134 or 144mm 1040
LIB660-B-11 660 11 860 203mm 235 or 245mm 134 or 144mm 1144
LIB660-B-12 660 12 936 203mm 235 or 245mm 134 or 144mm 1248
LIB660-B-13 660 13 1012 203mm 235 or 245mm 134 or 144mm 1352
LIB660-B-14 660 14 1088 203mm 235 or 245mm 134 or 144mm 1456
LIB660-B-15 660 15 1164 203mm 235 or 245mm 134 or 144mm 1560
Full Features
Brand MHS
